Lenovo ThinkPad Edge E530 Specifications

Lenovo
®
recommends Windows
®
7 Professional.
POWERFUL PERFORMANCE
The ThinkPad® Edge E530 boosts business performance using:
• 3rd generation Intel® Core™ processors with integrated graphics
• Enhanced Experience 3 for faster booting/resume and enhanced
battery life
• NVIDIA Optimus technology
2
that preserves longer battery life
combined with the power of discrete graphics
• Intel® HD with 80% up faster graphics performance
• Integrated HD 720p camera with face tracking captures high-
resolution video even in low light environments
• Lenovo Hard Disk Drive Performance Booster: Productivity testing
shows 184% increase in performance vs. normal Hard Disk Drive
systems
IMPROVED PRODUCTIVITY
The ThinkPad® Edge E530 gives your work both eectiveness and
versatility with:
• Dolby Advanced Audio for increased audio clarity on VOIP
applications and maximized volume output
• Various call modes for an outstanding VOIP experience
• Private Internet Call mode with dual array microphone and
improved audio recording clarity with the features, Echo
cancellation, Beam forming, and Noise Suppression
• Quick access to microphone, speaker and camera mute buttons,
working with VoIP has never been easier
STYLISH AND EFFICIENT
INSPIRED USABILITY
The ThinkPad® Edge E530 is designed to be stylish and durable
providing:
• Progressive clean design with multiple top cover colors for a
fashionable look and feel
• Midnight Black, Heatwave Red and Arctic Blue so touch paint
covers with a silver band adds to the style statement.
• Drop-down hinges shows attractive LCD screen and keyboard face
clean
• Enhanced keyboard design with numeric keypad and spill
resistance
3
The ThinkPad® Edge E530 provides many innovative usability features
including:
• USB 3.0 that powers data transfer at a rate ten times greater
than USB 2.0
• SimpleTap Deskband as a single point for notifications and
launching Lenovo Solution Center (LSC), Lenovo Solutions for
Small Business (LSSB)
THE LENOVO® THINKPAD® EDGE® E530 NOTEBOOK
1
Battery life improvement tests conducted in house using the Mobile Mark 2007 Standard
2
Optimus technology with battery savings is only available with Windows® 7 OS
3
E530 only
lenovo service
recommended services
* Not available in all regions
Lenovo oers a comprehensive portfolio of award-winning services to
support and protect your ThinkPad® Edge investment. Lenovo Services lets
you focus on your customers and business, not your IT.
Priority Technical Support *
Makes your priority, our priority. 24x7 priority call routing to advanced-
level technicians, electronic incident tracking, rapid response and
resolution.
Warranty Upgrades - Onsite Next Business Day Service
Maximizes PC uptime and productivity by providing convenient, fast repair
services at your home or oce.
Warranty Extensions (1 to 4 Years Total Duration)
This fixed-term, fixed-cost service helps accurately budget for PC
expenses, protect your valuable investment, and potentially lower the cost
of ownership over time.
Accidental Damage Protection
Avoid the hassles of unexpected repair costs. Provides coverage
for non-warranted damage incurred under normal operating
conditions, such as minor spills, drops, or damage to the
integrated screen
PART NUMBER: EPACK: 78Y1526,
PHYSICAL PACK: 78Y9370
WARRANTY UPGRADE TO 3-YEAR
ONSITE NEXT BUSINESS DAY
SERVICE WITH 3-YEAR ACCIDENTAL
DAMAGE PROTECTION FROM NON-
WARRANTED DAMAGE CONSTRAINTS

Lenovo ThinkPad Edge E530 Specifications

General

Bus type	DMI
Tjunction	105 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-3632QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	Socket 1224
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
Number of processors supported	1
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM77 Express
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD±RW
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD, SDHC, SDXC
Touchscreen	-
Display diagonal	15.6 \
Display brightness	220 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	500:1
Graphics card family	Intel, NVIDIA
Intel segment tagging	Home Office, Small Business
On-board graphics card ID	0x166
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	2 GB
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	HD
Speaker power	2 W
Number of built-in speakers	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Networking features	Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	ThinkPad UltraNav
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product color	Black
Battery life (max)	5.7 h
Number of battery cells	6
Password protection type	HDD, Power on, Supervisor
Cables included	AC
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Processor ARK ID	71458
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	245 mm
Width	377 mm
Weight	2450 g
Height (rear)	35.3 mm
Height (front)	29.5 mm
