Lenovo ThinkPad Edge E530 Specifications

Lenovo
®
recommends Windows
®
7 Professional.
WWW.LENOVO.COM /EUROPE
specifications
OPERATING SYSTEM PROCESSOR DISPLAY
Genuine Windows® 7 Home Premium 32-bit*
Genuine Windows® 7 Home Premium 64-bit
Genuine Windows® 7 Professional 64-bit
Linux*
Windows® 8 Ready
E530
Up to 2nd or 3rd generation Intel® Core® i7
Processor
E530
15.0” HD (with anti-glare and glossy options) &
15.0” HD+ Anti-glare
GRAPHICS WEBCAM MEMORY
GeForce GT 630M for 2nd or 3rd generation
Intel® Core® i3/i5/i7 processors
GeForce 610M for Intel® Pentium and Celeron
processors (optional)
720P HD Webcam Up to 8 GB DDR3 1600 MHz (2 DIMM slot)
BATTERY LIFE DIMENSIONS (W X D X H) WEIGHT
Up to” 8 hours (with Battery Safeguard
Hardware Authentication)
E530
31.1 mm = 1.2” (1.22 rounded down)
(14.8” x 9.6” x 1.1” - 1.2”)
E530
2.45 Kg
I/O (INPUT/OUTPUT) PORTS STORAGE AUDIO
(1) VGA
(1) HDMI 1.4
(3) USB 3.0
(1) USB 2.0 with powered “always on”
(1) RJ45
(1) 4-in-1 slot
500GB/750GB/1000GB (optional)
(5400 RPM)HDD
320GB/500GB(7200RPM) HDD
16GB SSD Cache for Lenovo Hard Disk Drive
Performance Booster (selected models only)
Stereo speakers with Dolby Advanced Audio
Enhancement
Dual array microphone with VOIP enhancement
Combo mic/headphone Jack
KEYBOARD FINGERPRINT READER WLAN
SMB Keyboard with Number pad Yes wifi a/b/g/n
WWAN BLUETOOTH BATTERY
Ericsson Bluetooth® 4.0 Combination with WLAN 6 cells 4400mAH
6 cells 5600mAH (optional)
MMG/WE/DS/Q4-12/27272
©2011 Lenovo. All rights reserved.
Availability: Offers, prices, specifications and availability may change without notice. Lenovo is not responsible for photographic or typographic errors.
Warranty: For a copy of applicable product warranties, write to: Warranty Support Dept., EMEA Services, Lenovo, Eisteinova 21, 851 01 Bratislava, Slovakia. Trademarks: Lenovo,
the Lenovo logo, Rescue and Recovery, ThinkPad, ThinkStation, ThinkVantage and ThinkVision are trademarks or registered trademarks of Lenovo. Microsoft, Windows and Vista are
registered trademarks of Microsoft Corporation. Intel, the Intel logo, Intel Core, Core Inside, Xeon and Xeon Inside are registered trademarks of Intel Corporation in the U.S. and other
countries. For more information about the Intel processor feature rating, please refer to www.intel.com/go/rating. Other company, product and service names may be trademarks or
service marks of others. Visit www.lenovo.com/safecomputing periodically for the latest information on safe and effective computing.
*Special bid only.
THE LENOVO® THINKPAD® EDGE® E530 NOTEBOOK

Lenovo ThinkPad Edge E530 Specifications

General

Bus type	DMI
Tjunction	105 °C
Processor cache	6 MB
Processor cores	4
Processor model	i7-3632QM
System bus rate	5 GT/s
Processor family	Intel® Core™ i7
Processor series	Intel Core i7-3600 Mobile series
Processor socket	Socket 1224
Processor threads	8
Processor codename	Ivy Bridge
Processor frequency	2.2 GHz
Processor cache type	Smart Cache
Processor lithography	22 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	3.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
Number of processors supported	1
CPU multiplier (bus/core ratio)	22
Maximum number of PCI Express lanes	16
Motherboard chipset	Intel HM77 Express
Memory slots	2x SO-DIMM
Internal memory	8 GB
Memory clock speed	1600 MHz
Internal memory type	DDR3-SDRAM
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD±RW
Card reader integrated	Yes
Total storage capacity	1000 GB
Compatible memory cards	MMC, SD, SDHC, SDXC
Touchscreen	-
Display diagonal	15.6 \
Display brightness	220 cd/m²
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Contrast ratio (typical)	500:1
Graphics card family	Intel, NVIDIA
Intel segment tagging	Home Office, Small Business
On-board graphics card ID	0x166
On-board graphics card model	Intel® HD Graphics 4000
Discrete graphics card memory	2 GB
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1150 MHz
Audio system	HD
Speaker power	2 W
Number of built-in speakers	2
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.0
Networking features	Gigabit Ethernet
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Charging port type	DC-in jack
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
eSATA/USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Pointing device	ThinkPad UltraNav
Operating system installed	Windows 8 Pro
Form factor	Clamshell
Product color	Black
Battery life (max)	5.7 h
Number of battery cells	6
Password protection type	HDD, Power on, Supervisor
Cables included	AC
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR
Processor ARK ID	71458
Processor package size	37.5 x 37.5 (rPGA988B) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	245 mm
Width	377 mm
Weight	2450 g
Height (rear)	35.3 mm
Height (front)	29.5 mm
