Lenovo ThinkPad Edge E535 Hardware Maintenance Manual

1180I/OsubcardwithUSBconnectorandaudiojack
Foraccess,removetheseFRUsinorder:
•“1010Batterypack”onpage62
•“1020Largebottomcover”onpage63
•“1040Opticaldriveorblankbezel”onpage65
•“1120Keyboard”onpage76
•“1130Keyboardbezel”onpage80
RemovalstepsofI/OsubcardwithUSBconnectorandaudiojack
1
2
3
Wheninstalling:Makesurethattheconnectorisattachedrmlytothesystemboard.
StepScrew(quantity)Color
Torque
3
M2×5mm,wafer-head,nylon-coated(1)Silver
0.181Nm
(1.85kgf-cm)
90HardwareMaintenanceManual
