Lenovo ThinkPad X220 Maintenance Manual

Table9.Partslist-Overall(continued)
No.FRUFRUno.
CRU
ID
5
SystemboardassemblywithIntelCorei5-2520Mprocessor,AMT,non-TPM,non-AES
•4294-CTO,2Ax
•4296-CTO,3Dx
•4297-CTO
•4298-CTO,4Ax,49x
•4299-CTO
•4300-CTO
•4301-CTO
04W2131N
5
SystemboardassemblywithIntelCorei5-2520Mprocessor,non-AMT,TPM,AES
•4294-CTO,2Rx,2Kx
•4296-CTO,26x,27x
•4297-CTO
•4298-CTO,4Xx,4Jx,46x,45x
•4299-CTO,3Bx
•4300-CTO
•4301-CTO
04W2129N
5
SystemboardassemblywithIntelCorei5-2520Mprocessor,non-AMT,non-TPM,non-AES
•4294-CTO,29x,28x
•4296-CTO,3Ax,28x
•4297-CTO
•4298-CTO
•4299-CTO
•4300-CTO
•4301-CTO
04W2133N
5
SystemboardassemblywithIntelCorei7-2620Mprocessor,AMT,TPM,AES
•4294-CTO,22x
•4296-CTO,3Ex,39x,38x,37x,35x,34x,2Zx,2Yx,2Ux,2Px,2Nx,2Ex,2Dx
•4297-CTO
•4298-CTO,4Ux,4Dx,48x,47x,44x,43x,3Yx,3Xx,3Ux,3Tx,3Lx,3Kx,3Hx,3Gx,3Fx,
35x,32x,2Yx,2Wx,2Ux,2Tx,2Fx,2Ex,2Cx,2Bx,29x,26x
•4299-CTO,54x,4Yx,3Ex,3Dx,3Cx,3Ax,39x,38x,37x,34x,33x,32x,2Zx,2Sx,2Rx,
2Lx,2Gx,2Ex,2Dx,2Bx,29x,26x
•4300-CTO
•4301-CTO
04W2128N
5
SystemboardassemblywithIntelCorei7-2620Mprocessor,AMT,non-TPM,non-AES
•4294-CTO,2Ax
•4296-CTO,3Dx
•4297-CTO
•4298-CTO
•4299-CTO
•4300-CTO
•4301-CTO
04W2132N
5
SystemboardassemblywithIntelCorei7-2620Mprocessor,non-AMT,TPM,AES
•4294-CTO
•4296-CTO
•4297-CTO
•4298-CTO
•4299-CTO
•4300-CTO
•4301-CTO
04W2130N
110HardwareMaintenanceManual

Lenovo ThinkPad X220 Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-2520M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-2500 Mobile Series
Processor socket	Socket 988
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	8 GB
HDD capacity	160 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
HDD interface	SATA
Card reader integrated	Yes
Compatible memory cards	SD
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Graphics card	HD Graphics
Power supply type	AC/DC
Wireless technology	802.11a/g/n
Compatible operating systems	Windows 7 Home Basic Windows 7 Home Premium Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
Operating system installed	Windows 7 Professional
Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Product color	Black
Processor code	SR048
Processor ARK ID	52229
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
On-board graphics card ID	0x116
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz

Weight and Dimensions

Depth	228.7 mm
Width	305 mm
Height	31.3 mm
Weight	1760 g
