Lenovo ThinkPad X220 Maintenance Manual

Table9.Partslist-Overall(continued)
No.FRUFRUno.
CRU
ID
6
IntegratedChinaTelecomMobileBroadband(HuaweiEM660)
•4294-CTO
•4296-CTO
•4297-CTO
•4298-CTO,4Lx,4Kx,3Hx,3Gx,3Bx,3Ax
•4299-CTO
•4300-CTO
•4301-CTO
60Y3239**
7
ThinkPadb/g/nWireless(1x1BGN)
•4294-CTO,28x,29x
•4296-CTO
•4297-CTO
•4298-CTO
•4299-CTO
•4300-CTO
•4301-CTO
60Y3247**
7
ThinkPadb/g/nWireless(1x1BGN)
•4294-CTO,28x,29x
•4296-CTO
•4297-CTO
•4298-CTO
•4299-CTO
•4300-CTO
•4301-CTO
60Y3249**
7
IntelCentrinoWireless-N1000
•4294-CTO,2Rx,2Qx,2Px,2Kx,2Gx,2Fx,2Ex,2Cx,2Bx,27x,26x
•4296-CTO,3Ax,29x,28x,27x,26x,3Hx,3Gx,2Tx,2Sx,2Rx,2Qx,2Cx,25x,24x
•4297-CTO,22x
•4298-CTO,4Xx,4Px,4Nx,4Jx,46x,45x,4Wx,3Nx,36x
•4299-CTO,2Mx,3Bx
•4300-CTO
•4301-CTO
60Y3241**
7
IntelCentrinoAdvanced-N6205(2x2AGN)
•4294-CTO,2Sx,2Nx,2Mx,2Lx,2Jx,2Hx,2Ax,22x,24x,2Dx,25x
•4296-CTO,3Mx,3Lx,3Ex,3Dx,3Bx,39x,38x,37x,36x,35x,34x,33x,32x,2Zx,2Yx,
2Xx,2Wx,2Ux,2Px,2Nx,2Mx,2Lx,2Kx,2Ex,2Dx,2Bx,22x,3Qx,3Px,3Nx,3Kx,3Fx,
2Jx,2Hx,2Gx,2Fx,23x
•4297-CTO,23x,24x
•4298-CTO,53x,52x,4Yx,4Vx,4Ux,4Tx,4Sx,4Rx,4Qx,4Mx,4Lx,4Kx,4Hx,4Gx,4Dx,
4Cx,4Bx,4Ax,49x,48x,47x,44x,43x,42x,3Zx,3Yx,3Xx,3Wx,3Vx,3Ux,3Tx,3Sx,3Rx,
3Qx,3Px,3Mx,3Lx,3Kx,3Jx,3Hx,3Gx,3Fx,3Ex,3Dx,3Cx,3Bx,3Ax,39x,38x,37x,
35x,34x,33x,32x,2Zx,2Yx,2Xx,2Wx,2Vx,2Ux,2Tx,2Sx,2Rx,2Qx,2Px,2Nx,2Mx,
2Lx,2Kx,2Jx,2Hx,2Gx,2Fx,2Ex,2Dx,2Cx,2Bx,2Ax,29x,28x,27x,4Zx,4Fx,4Ex
•4299-CTO,54x,53x,52x,4Zx,4Yx,4Xx,4Wx,4Vx,4Ux,4Tx,4Cx,4Bx,3Ex,3Dx,3Cx,
3Ax,36x,35x,34x,33x,32x,2Zx,2Yx,2Xx,2Wx,2Vx,2Ux,2Tx,2Sx,2Rx,2Qx,2Px,2Lx,
2Kx,2Jx,2Hx,2Gx,2Fx,2Ex,2Cx,2Bx,2Ax,29x,28x,27x,2Nx
•4300-CTO
•4301-CTO
60Y3253**
Chapter10.Partslist117

Lenovo ThinkPad X220 Specifications

General

Bus type	DMI
Stepping	J1
Tjunction	100 °C
Processor cache	3 MB
Processor cores	2
Processor model	i5-2520M
System bus rate	5 GT/s
Processor family	Intel® Core™ i5
Processor series	Intel Core i5-2500 Mobile Series
Processor socket	Socket 988
Processor threads	4
Processor codename	Sandy Bridge
Processor frequency	2.5 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.2 GHz
Processor operating modes	64-bit
ECC supported by processor	No
PCI Express configurations	1x16, 2x8, 1x8+2x4
Thermal Design Power (TDP)	35 W
CPU multiplier (bus/core ratio)	25
Maximum number of PCI Express lanes	16
Internal memory	4 GB
Memory clock speed	1333 MHz
Maximum internal memory	8 GB
HDD capacity	160 GB
SSD capacity	The Solid State Drive's storage capacity in Gigabytes.
HDD interface	SATA
Card reader integrated	Yes
Compatible memory cards	SD
Display diagonal	12.5 \
Display resolution	1366 x 768 pixels
Native aspect ratio	16:9
Graphics card	HD Graphics
Power supply type	AC/DC
Wireless technology	802.11a/g/n
Compatible operating systems	Windows 7 Home Basic Windows 7 Home Premium Windows 7 Professional
Charging port type	DC-in jack
USB 2.0 ports quantity	3
Ethernet LAN (RJ-45) ports	1
Operating system installed	Windows 7 Professional
Form factor	Convertible (Swivel)
Product type	Hybrid (2-in-1)
Product color	Black
Processor code	SR048
Processor ARK ID	52229
Processor package size	37.5 x 37.5 (rPGA988B); 31 x 24 (BGA1023) mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00
On-board graphics card ID	0x116
On-board graphics card model	Intel® HD Graphics 3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	650 MHz
On-board graphics card dynamic frequency (max)	1300 MHz

Weight and Dimensions

Depth	228.7 mm
Width	305 mm
Height	31.3 mm
Weight	1760 g
