Note: If there are system fans installed in the system fan cage, ensure that the system fans are
correctly connected to the system fan connectors on the system board.
Step 2. Rotate the levers of the system fan cage to the front of the server to secure the system fan cage.
Install a system fan
Use this information to install a system fan.
About this task
Attention:
• Read “Installation Guidelines” on page 134 to ensure that you work safely.
• Power off the server and disconnect all power cords for this task.
• Prevent exposure to static electricity, which might lead to system halt and loss of data, by keeping static-
sensitive components in their static-protective packages until installation, and handling these devices with
an electrostatic-discharge wrist strap or other grounding system.
• Before installing a system fan, ensure that you have selected the required system fan. See “Technical
rules for system fans” on page 152.
S033
CAUTION:
Hazardous energy present. Voltages with hazardous energy might cause heating when shorted with
metal, which might result in spattered metal, burns, or both.
S017
CAUTION:
Hazardous moving fan blades nearby.
A video for this task is available at:
• Youtube:
https://www.youtube.com/playlist?list=PLYV5R7hVcs-Bz2XIeLEfGcrLGm9TSY_yt
• Youku: http://list.youku.com/albumlist/show/id_52339612.html
Procedure
Step 1. Touch the static-protective package that contains the new system fan to any unpainted surface on
the outside of the server. Then, take the new system fan out of the package and place it on a static-
protective surface.
Chapter 4. Server hardware setup 223
