Commissioning
Using the keypad E82ZBC − Parameter setting
7
EDK82EV113 DE/EN/FR 8.1
119
L
Change and save parameters
) Note!
The menu user is active after mains switching. Change to the menu all to
address all codes.
Action Keys Result Note
1. Plug in the keypad
xx.xx Hz
Function is activated. The first code in the user menu will
be displayed (C0517/1, Lenze setting: C0050 = output
frequency).
2.
If necessary change to the
menu "ALL"
Change to function bar 2
3.
4.
all
Select menu "ALL" (list of all codes)
5.
Confirm selection and change to function bar 1
6. Inhibit controller
Only necessary if you want to change C0002, C0148, C0174
and/or C0469
7.
Set parameters
8.
XXXX
Select code
9.
001
For codes without subcodes: Jump automatically to
10.
XXX
Select subcode
11.
12.
XXXXX
Set parameters
13.
STOre Confirm entry if blinking
Confirm entry if is not blinking; is not active
14. Restart the "loop" at 7. to set other parmeters.
