Firmware ≤ 02.00 - DMS 2.1 EN - 03/2011 L 139
8400 motec | Software Manual
I/O terminals
User-defined terminal assignment
6.3 User-defined terminal assignment
In order to individually adapt the preconfigured assignment of the input/output terminals
to your application, you can choose one of the following procedures:
A. In the »Engineer«:
– Change the terminal assignment on the Terminal assignment tab.
– Change the signal assignment on the Application Parameters tab, on the dialog level
Overview Signal flow.
B. In the »Engineer« or with the keypad:
– Change the parameters for signal configuration in the parameters list.
Tip!
First set a suitable Lenze configuration by selecting a corresponding control mode
in C00007
.
We recommend using the »Engineer« for the implementation of comprehensive
user-defined drive solutions.
Note!
If you change the preconfigured assignment of the input/output terminals, the
terminal assignment will be a user-defined one. In C00007
, control mode "0:
Interconnection changed" will be shown.
