Configuration
Overview of monitoring functions
8
8.4
8.4−1
EDSVF9383V EN 7.1−04/2012
8.4 Overview of monitoring functions
The responses of monitoring functions can be partly parameterised via codes ˘ in GDC in the parameter menu under
Monitoring ˘.
Monitoring Possible responses
l Lenze setting
ü Setting possible
Error message Description Source
CoDe TRIP Message Warning Off
0071 CCr System fault Internal l
x091 EEr External monitoring (activated via DCTRL) FWM C0581 l ü ü ü
Voltage supply
2020 OU Overvoltage in the DC bus (C0173) MCTRL l
1030 LU Undervoltage in the DC bus (C0173) MCTRL l
0107 H07 Internal fault (power section) Internal l
Communication
x061 CE0 Communication error on the automation interface (AIF) AIF C0126 ü ü l
x062 CE1 Communication error at process data input object CAN1_IN (monitoring time can be set
with C0357/1)
CAN1_IN C0591 ü ü l
x063 CE2 Communication error at process data input object CAN2_IN (monitoring time can be set
with C0357/2)
CAN2_IN C0592 ü ü l
x064 CE3 Communication error at process data input object CAN3_IN (monitoring time can be set
with C0357/3)
CAN3_IN C0593 ü ü l
x065 CE4 BUS−OFF state of the system bus (CAN)
(too many faulty telegrams)
CAN C0595 ü ü l
Temperatures / sensors
0050 OH Heatsink temperature > 85° C MCTRL l
x053 OH3 Motor temperature > 150° C MCTRL C0583 ü ü l
x054 OH4 Heatsink temperature > C0122 MCTRL C0582 l ü
x057 OH7 Motor temperature > C0121 MCTRL C0584 l ü
x058 OH8 Motor temperature across inputs T1 and T2 is too high.
Please note: In the case of "Warning" (C0585 = 2) or "Off" (C0585 = 3), the drive can be
destroyed if the fault is not eliminated in time!
MCTRL C0585 ü ü l
x086 Sd6 Thermal sensor error at motor (X7 or X8) MCTRL C0594 ü ü l
x110 H10 Thermal sensor error at heatsink FWM C0588 l
1) 1)
x111 H11 Thermal sensor error in the device interior FWM C0588 l
1) 1)
Motor / feedback system
0011 OC1 Motor cable overcurrent MCTRL l
0012 OC2 Motor cable earth fault MCTRL l
0013 OC3 Overload at acceleration or deceleration MCTRL l
