Function library
7-220
L
EDSVS9332P-D21 EN 3.0
7.5.60.3 Torque limitation
Via the inputs MCTRL-LO-M-LIM and MCTRL-HI-M-LIM an external torque limitation can be set.
This serves to set different torques for the quadrants ”driving” and ”braking”.
•
MCTRL-HI-M-LIM is the upper torque limit in [%] of the max. possible torque (C0057).
•
MCTRL-LO-M-LIM is the lower torque limit in [%] of the max. possible torque (C0057).
•
In case of quick stop (QSP) the torque limitation is deactivated.
Stop!
Only set positive values in MCTRL-HI-M-LIM and negative values in MCTRL-LO-M-LIM, otherwise
the speed controller may lose control. The drive may accelerate uncontrollably.
