Configuration
Function blocks
Internal motor control with V/f characteristic control (MCTRL1)
8
8.2
8.2.6
8.2−29
EDSVF9383V EN 7.1−04/2012
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C0078 Tn slip CTRL 100 1 {1 ms} 6000 Integral−action time of slip
controller
l Filter time for slip
compensation (C0021)
l Only active with V/f
characteristic control
8.2−25
C0086
Mot type à Motor selection list Motor type selection
à depending on the controller
used
l Motor selection in C0086 sets
the corresponding parameters
in C0021, C0022, C0081,
C0087, C0088, C0089, C0090,
C0091
6.6−1
C0087
Mot speed à 50 {1 rpm} 36000 Rated motor speed
à depending on C0086
l Motor selection in C0086 set
the corresponding rated motor
speed in C0087
l Change of C0087 sets
C0086 = 0
6.6−1
C0089
Mot frequency à 10 {1 Hz} 5000 Rated motor frequency
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
frequency in C0089
l Change of C0089 sets
C0086 = 0
6.6−1
C0090
Mot voltage à 0 {1 V} 1000 Rated motor voltage
à depending on C0086
l Motor selection in C0086 sets
the corresponding rated motor
voltage in C0090
l Change of C0090 sets C0086 =
0
6.6−1
C0095
Mot Io à 0.0 {0.1 A} 1000.0 Motor magnetising current
à dependent on C0086, C0088
and C0091
l Change of C0086 sets C0095 to
the Lenze setting
l Change of C0095 sets
C0086 = 0
6.6−1
C0105 QSP Tif 5.00 0.00 {0.01 s} 999.90 Quick stop deceleration time
l The deceleration time refers to
a speed variation of C0011 ... 0
8.2−25
8.2−40
C0107 holding time 0.00 0.00 {0.01 s} 9999.90 Hold time for automatic DC
injection braking (Auto−GSB)
8.2−25
8.2−40
C0143 limit 2 kHz 0.0 0.0 {0.1 Hz} 20.0 Speed−dependent switching
threshold
l Threshold for automatic
switching frequency reduction
l The controller changes
automatically to 2 kHz when
this value falls below the
threshold
8.2−25
8.2−40
