Configuration
Overview of monitoring functions
8
8.4

8.4−2
EDSVF9383V EN 7.1−04/2012
Possible responses
l Lenze setting
ü Setting possible
Monitoring
OffWarningMessageTRIPCoDe
SourceDescriptionError message
0015 OC5 I x t overload MCTRL l
0016 OC6 I
2
x t overload MCTRL l
0018 OC8 I
2
x t overload advance warning MCTRL C0606 ü l ü
x032 LP1 Motor phase failure
(current limit can be set in C0599)
Please note: Can only be used for asynchronous motors. The function block MLP1 has to
be entered in C0465.
MCTRL C0597 ü ü l
x083 Sd3 Interruption of the digital frequency coupling. The input signal ˜Lamp Control˜ at X9/8
is LOW
Please note: In the case of "Warning" (C0587 = 2), the drive can be destroyed if the
fault is not eliminated in time!
MCTRL C0587 l ü ü
x085 Sd5 At analog input X6/1, X6/2, the input current is < 2 mA
Monitoring only possible if C0034 = 1
MCTRL C0598 ü ü l
0140 ID1 Motor data identifcation − characteristic MCTRL l
0141 ID2 Motor data identification − motor data MCTRL l
Speed
0200 NMAX Maximum speed (C0596) has been exceeded. MCTRL l
Time−out / overflow
0105 H05 Intern fault (memory) Internal l
Parameter setting
0072 PR1 Checksum error in parameter set 1 Internal l
0073 PR2 Checksum error in parameter set 2 Internal l
0074 PEr Program error Internal l
0075 PR0 Error in the parameter sets Internal l
0077 PR3 Checksum error in parameter set 3 Internal l
0078 PR4 Checksum error in parameter set 4 Internal l
0079 PI Fault during the parameter initialisation Internal l
Representation of the error number:
x 0 = TRIP, 1 = message, 2 = warning
E. g. "2091": An external monitoring has triggered EEr warning
1)
Setting only permitted by Lenze service
