Configuration
Code table
8
8.5
8.5−65
EDSVF9383V EN 4.0−03/2006
IMPORTANTPossible settingsCode
SelectionLenzeNameNo.
C1330 PCTRL2 Tir 1.0 0.1 {0.1 s 6000.0 Acceleration time t
ir
, function
block PCTRL2
l Acceleration time for the
setpoint
l The acceleration time refers to
a setpoint change of 0 ... 100 %
See System
Manual
(extension)
C1331 PCTRL2 Tif 1.0 0.1 {0.1 s} 6000.0 Deceleration time t
if
, function
block PCTRL2
l Deceleration time for the
setpoint
l The deceleration time refers to
a setpoint change of 100 % ... 0
C1332 PCTRL2 Vp 1.0 0.1 {0.1 } 500.0 Gain V
p
, function block PCTRL2
See System
Manual
(extension)
C1333 PCTRL2 Tn 400 20 {1 ms} 99999 Integral−action time T
n
, function
block PCTRL2
Setting of reset time T
n
of PCTRL2
C1334 PCTRL2 Kd 0.0 0.0 {0.1 } 5.0 Differential component K
d
,
function block PCTRL2
C1335 bipolar/
unipolar
0
Sphere of action, function block
PCTRL2
0 Bipolar l Output value is limited to
−100 ... 100 %
See System
Manual
(extension)
1 Unipolar l Output value is limited to
0 ... 100 %
C1336 Tir overlay 1.0 0.1 {0.1 s} 6000.0 Fade−in time, function block
PCTRL2
l Acceleration time of the ramp
generator
l Controls the influence of the
process controller
See System
Manual
(extension)
C1337 Tif overlay 1.0 0.1 {0.1 s} 6000.0 Fade−out time, function block
PCTRL2
l Deceleration time of the ramp
generator
l Controls the influence of the
process controller
C1340
Selection list 1 Configuration of analog input
signals, function block PCTRL2
See System
Manual
(extension)
1 CFG: RFG−SET 1000 FIXED0% l The process setpoint is shown
at PCTRL2−SET with a starting
value via a ramp generator
l PCTRL−RFG−LOAD = HIGH
activates the function
2 CFG: SET 1000 FIXED0% l Input for process value
l Value range: ±200 %
3 CFG: ACT 1000 FIXED0% l Input for actual value
l Value range: ±200 %
4 CFG: INFL 1000 FIXED0% l Evaluation (influence) of the
output signal
l Value range: ±200 %
