8.7 Table of attributes
The attribute table describes the properties of the codes used. It enables you
to create your own communication programs for the controller.
How to read the table of attributes
Column Abbreviation Meaning
Code Cxxxx Name of the Lenze code
Index
dec 24575 − Lenze code
number
Index under which the
parameter is addressed
The subindex of array variables
corresponds to the Lenze
subcode number
Is only required for control via INTERBUS,
PROFIBUS DP or system bus (CAN)
hex 5FFFh − Lenze code
number
Data DS
E
Data structure
Single variable
(only one parameter element)
A Array variable
(several parameter elements)
DA xx Number of array elements
(subcodes)
DT
B8
Data type
1 byte bit−coded
B16 2 bytes bit−coded
B32 4 bytes bit−coded
FIX32 32−bit value with sign;
decimal with four decimal places
I32 4 bytes with sign
U32 4 bytes without sign
VS ASCII string
Format
VD
LECOM format
(see also Operating Instructions
of the bus module)
ASCII decimal format
VH ASCII hexadecimal format
VS String format
VO Octet string format for data blocks
DL Data length in byte The column "Important" contains further
information
Access LCM−R/W
Ra
Access authorisation for LECOM
Reading is always permitted
Wa Writing is always permitted
W Writing is restricted
Condition CINH Condition for writing Writing permitted only when controller is
inhibited
