Short Circuit Current Rangs (SCCR) with Semiconductor Fuses
(Tested per UL61800-5-1, reference UL le E132659)
Inverter Alternate Fuse (Semiconductor Fuse)
Mains Rated power Max. SCCR Max. rated current
kW hp kA A
230 V, 1/3-ph 0.37 0.5 50 50
230 V, 1/3-ph 0.55 0.75 50 50
230 V, 1/3-ph 0.75 1 50 50
230 V, 1/3-ph 1.5 2 50 50
230 V, 3-ph 2.2 3 50 50
230 V, 3-ph 4 5 50 100
230 V, 3-ph 5.5 7.5 50 100
480 V, 3-ph 0.55 0.75 50 50
480 V, 3-ph 0.75 1 50 50
480 V, 3-ph 2.2 3 50 50
480 V, 3-ph 4 5 50 50
480 V, 3-ph 7.5 10 50 100
480 V, 3-ph 11 15 50 100
480 V, 3-ph 15 20 50 100
480 V, 3-ph 22 30 50 200
480 V, 3-ph 30 40 50 250
480 V, 3-ph 45 60 50 250
480 V, 3-ph 55 75 50 315
480 V, 3-ph 75 100 50 315
480 V, 3-ph 90 125 50 350
480 V, 3-ph 110 150 50 350
Manufacturer Max. rated current Designaon
A
Eaton/Bussmann
50
FWP-50A14Fa, FWP-50A22F, FWP-50B
170M1314, 170M1364, 170M1414, 170M1733, 170M1753
100
FWP-100A22F, FWP-100B
170M1317, 170M1367, 170M1417, 170M1736, 170M1756
200
FWP-200A
170M1320, 170M1370, 170M1420, 170M1739, 170M1759
250
FWP-250A
170M1321, 170M1371, 170M1421, 170M1740, 170M1760
315 170M1322, 170M1372, 170M1422, 170M1741, 170M1761
350
FWP-350A
170M1742, 170M1762
Lielfuse
50 L70QS050
100 L70QS100
200 L70QS200
250 L70QS250
350 L70QS350
Mersen
50 A70QS50-22F, A70QS50-14F, A70QS50-14FI, A70QS50-22FI, A70QS50-4
100 A70QS100-4, A70QS100-22F, A70QS100-22FI
200 A70QS200-4, A70QS200-4K
250 A70QS250-4
350 A70QS350-4
Electrical ins
tallaon
Connecon according to UL
Fusing data
134
