Control c
onnecons
Digital inputs
X3: DI1, DI2, DI3, DI4 / GI
Switching type PNP Parameterizable
Use case 1 Standard digital input
Use case 2 Touch probe input Maximum of 8 markers per ms detectable with a
temporal resoluon of 10 ns.
Switching level PNP
LOW V < + 5 IEC 61131−2, type 1
HIGH V > + 15
Input resistance kΩ 4.6
Sampling frequency of digital
inputs
kHz 4 When used as standard digital input.
MHz 100 When used as touch probe.
Electric strength of external
voltage
V ± 30
Digital outputs
X3: DO1 / 24O / GO
Switching level
LOW V < + 5 IEC 61131-2, type 1
HIGH V > + 15
Max. output current, DO1 mA 50
Cycle me ms 0.25
Short-circuit strength Unlimited period
Electric strength of external
v
oltage
V ± 30
Suppressor circuit Integrated varistor
Overload behavior Reduced voltage or periodic switch-o/on
Time response µs 250 LOW - HIGH / HIGH - LOW
Reset or switch-on behavior Output is switched o LOW
Connecon descripon Control terminals 24 V supply for control
electr
onics
PTC input
Connecon X3 X5 X109
Connecon type Pluggable Pluggable Pluggable
Max. cable cross-secon mm² 1.5 2.5 1.5
Max. cable cross-secon AWG 16 12 14
Stripping length mm 9 10 6
Stripping length in 0.35 0.39 0.2
Required tool Screwdriver 0.4 x 2.5
Electrical ins
tallaon
Control connecons
154
