Connecon of one c
able technology (OCT) via HIPERFACE DSL®
Precondions
•
The One Cable Technology is only available in the devices < 22 kW.
•
The One Cable Technology (OCT) is possible with MCS and m850 servo motors.
•
The motor must be provided with a HIPERFACE DSL® encoder.
•
Make sure that no motor encoder module is plugged in slot A.
•
Connecon cable:
-
The hybrid cable EYP008xxxxxxM11A00 or EYP008xxxxxxM12A00 must be used.
-
Various lengths up to 100 m are available.
The hybrid cables have only basic insulaon t
o the power electronics.
•
The use of One Cable T
echnology (OCT) depends on the combinaon of the basic device
rmware with the safety rmware:
Use of One Cable Technology (OCT)
Basic device rm
ware As of V01.06.04 V01.05.03 V01.05.02 V01.04.02 V01.04.01 V01.03.07 V01.02.03 V01.01.03
Safety rmware As of V01.03.03 V01.02.03 V01.02.03 V01.02.03 V01.02.03 V01.01.01 V01.00.01 -
With device variant
"Basic Safety - STO" ● ● ● ● ● ● - -
"Extended Safety" ● - - - - - - -
Cable preparaon
a
c
b
U
V
W
PE
T1
T2
BD1
BD2
1
0
23
bk 1
bk 2
bk 3
bk 5
gnye
bk 6
wh
bl
Fig. 13: Cable assembly
A Hybrid cable
B
Shield
C Conducve foil
D Heat-shrinkable tube
Inverter I95AE
137D 155D 175D 215D 222C 240C 255C
155F 175F 222F 240F 275F 311F 315F
Rated power P
N
kW 0.37 0.55 0.75 1.5 2.2 4 5.5 7.5 11 15
Rated power P
N
HP 0.5 0.75 1 2 3 5 7.5 10 15 20
Stripping length a mm 100 140
b mm 200 220
c mm 25 30
Electrical ins
tallaon
Connecon of one cable technology (OCT) via HIPERFACE DSL®
156
