Lenze I95AE222F Mounting And Switch-On Instructions

3-phase mains c
onnecon 480 V
Rated data
Inverter I95AE
155F 175F 222F 240F 275F 311F 315F
Rated power P
r
ated
kW 0.55 0.75 2.2 4 7.5 11 15
Rated power P
rated
hp 0.75 1 3 5 10 15 20
Mains voltage range 3/PE AC 340 V ... 528 V, 45 Hz ... 65 Hz
Output voltage 3 AC 0 - 400/480 V
Rated mains current
without mains choke A 2.1 2.8 6.5 10.5 16.6 23.7 -
with mains choke A 1.7 2.2 4.4 7.5 13.1 18.6 24
Apparent output power kVA 1.2 1.6 3.8 6.4 11 16 22
Rated output current
2 kHz A 1.6 2.1 4.8 8.2 14 21 27
4 kHz A 1.6 2.1 4.8 8.2 14 21 27
8 kHz A 1.6 2.1 4.8 6.2 14 21 19.8
16 kHz A 1.1 1.4 2.2 2.5 7.8 7.2
Power loss
2 kHz W 33 39 71 111 186 256 342
4 kHz W 34 41 75 117 197 272 363
8 kHz W 40 49 94 149 252 351 471
16 kHz W 40 49 94 149 252 351 471
Cyclic mains switching 3 mes per minute
Max. motor cable length
shielded
without EMC category m 50 100
Category C1 (2 kHz, 4 kHz,
8 kHz)
m -
Category C2 (2 kHz, 4 kHz,
8 kHz)
m 20
Category C3 (2 kHz, 4 kHz,
8 kHz)
m 35
Weight m kg 1.6 3.9
Weight m lb 3.5 8.6
Technical data
3-phase mains c
onnecon 480 V
Rated data
178

Lenze I95AE222F Specifications

General

Brand	Lenze
Model	I95AE222F
Category	Inverter
Language	English
