Equipment
The following gure provides an overview of the elements and connecons on the product.
Their posion, size and appearance may vary.
Motor connection
(depending on
the mounting position)
Oil filler plug
(depending on the
mounting position)
Ventilation
(depending on
the mounting position)
Oil control plug
Housing type
Output flange
Output shaft
Brake
Cooling
Feedback
Temperature monitoring
(depending on the
mounting position)
Oil drain plug
