- 8 -
FlexMount Bracket : FLEX
4x 4x 4x4x
Wood ScrewBonded WasherDrywall Anchor Drywall Screw
Attach Bracket Plate to wall
with Wood Screws or Drywall Anchors
*Thread Speaker Wire through Bracket Plate
