Leonard TM-2020B-3PS User Manual

SMALL TM VALVE PARTS
& PKG. (2 EACH)
KIT R/28 REBUILDING KIT
KIT 4/M20 CHECKSTOP KIT
CONTROL ASSEMBLY
KIT 1/26 PACKINGS & GASKETS
LOWER STEM
O'RING (2 EACH)
HOLDER NUT
LOWER STEM
& PACKING
BONNET PKG.
2 EACH:
M20-6A
M20-3C
GASKET
COVER
(2 EACH)
GLAND PKG.
M20-3A
(2 EACH)
MU-4C
STEM O'RING
MU-5A UPPER
GASKET
M20-3C
COVER
M20-3A
BONNET PKG.
TM-28-1-12B
THERMOSTATIC
(2 EACH)
O'RING
MU-5A
M20-6A
TM-28-6B
CHECK SPRING
CHECK SPRING
M20-9A
M20-9A
(2 EACH)
REMEMBER! THIS IS A CONTROL DEVICE
WHICH MUST BE CLEANED AND
MAINTAINED ON A REGULAR BASIS (SEE
MAINTENANCE GUIDE AND RECORD)
NOTE: AFTER INSTALLING NEW PARTS IT
WILL BE NECESSARY TO RESET THE
ADJUSTABLE HIGH TEMPERATURE LIMIT
STOP ON EACH VALVE (SEE PAGE 2).
CHECKSTOP PARTS REPAIR KITS
MU-4A RF
MU-5A UPPER
CHECKSTOPS
STEM PKG.
M20-3A BONNET
PACKING
AND PACKING
UPPER STEM
CHECK SPRING
M20-6A LOWER
STEM & PACKING
M20-9A
CHECK BONNET
M20-2A RF
MU-10B
GLAND NUT
GLAND PACKING
(2 RE Q'D)
TM-28-1-8B
BRIDGE ASSEMBLY
(2 RE Q'D)
TGM-1/28
BRIDGE
(2 RE Q'D)
HOL DER NUT O'RING
TM-28-6B
TM25-5
P.S. PACKING
(2 RE Q'D)
PORT SLEEVE
TM25-3B
ASSEMBLY
POINTER ROD NUT
M20-1C RF/CP
P.S . HOLDER NUT
MU-4C
TM-25-3A
DIAL PLATE
57-D RF
COVER
TM28-G2
THERMOSTAT GROUP
(2 REQ'D)
TM25-3
P.S. HOLDER
M20-3C
GASKET
COVER
03307
POINTER
7628
LTR SET SCREW
6910
POINTER SCREW
7520
7
