FGP-1031
x 1
Power Cord
x 1
Manual/QIG
x 1
P
ackage Content
Function Switch
Mark Mode
Description
N
V
S
Standard Normal
Port Isolation
Super Mode
All ports communicate freely,adapting to common data transmission environment
Switch to VLAN mode;downlink isolating from each other,uploads and downloads data
through uplink;suppress network failure like broadcast storm and virus attack
Downlink speed limitation:10M(Ultral-far transmission:250 meters)
Indicator
Status
Always ON
Always OFF
Flashes
Port circuit or cunrrent over-loaded
Port Isolation LED：V
Super Mode LED：S
Port Isolation mode ON
Super mode ON
PoE LED
Orange
Green
Powered equipments connected and power supply narmally
No powered equipments connected or no power supply
Network signal communicated
Network signal not communicated
Indicator
Description
Normal
Power Unconnected
Always ON
Always ON
Always ON
Always OFF
Always OFF
Always ON
Power LED:P
100M PoE port 1000M Uplink
Function switch
Indicator
