Installation
(1) Plug the input power cord into AC input socket.
(2) Connect output signal wire separately.
(3) Tight connection of AC lead-in wire, signal wire, output wire to avoid poor or loose
contact.
Attention 1: The installation of remote power supply should keep away from heat
sources, electromagnetic interference, non-corrosive gases and metal dust.
Attention 2: No blocking to the machine cooling holes.
Attention 3: Smooth placement and no violent vibration when installing.
Attention 4: Attend if the AC input voltage is between 100VAC~160VAC.
Attention 5: During installation, avoid any damage caused by collision and friction with
other equipment.
Auto-detection of receiving end
Auto-management of power
AC input voltage AC 100 - 160V，50 to 60Hz
Power supply Built-in 400W
LED indicator Power light; PoE output light
Connector Isolation RJ-45，EIA 568A and568B
Protocol Meet IEEE802.3af，IEEE802.3at standard
Environment and Physical Properties
Working temperature -0～40℃
Stocking temperature -40～85℃
Humidity ≤95％ ( non-condensing)
Weight 5kg
Dimension 440*235*43 mm
Installation 19” Frame
