Step 2: Connection to PoE PD
B. Connect the OUT1 & OUT2 port of P0R-1102 to power up the PD device as the following
connection.
** Note: If the Ethernet cable is not standard CAT5 cable, the POR1102 may be working for shorter
length than 100 meter.
V1.0
POR-1102
POE
Ethernet Switch
100 m 100 m
Power
PD1
PD2
