LAMP HOUSING ASSEMBLY
Ref. Qty. Description Item Number
1 1 Right housing
2 1 Left housing
3 1 Top housing
4 1 Focus track
5 1 Front cover
6 1 Rear cover
7 1 Standoff disk N00-HD237-690
PLATFORM ASSEMBLY — THEATER FRESNEL
Ref. Qty. Description Item Number
41 4 Rivet, 1/8" x 7/32"
42 1 Reflector
43 2 Rivet, 1/8" x 5/16"
44 1 Reflector mount
45 2 Washer, internal tooth, #4
46 2 Screw, pan head, 4-40 x 3/8"
47 4 Carriage assembly guide N00-SM275-250
48 1 Lampholder platform N03-SM280-640
49 1 Lampholder, prefocus N01-SK021-230
PLATFORM ASSEMBLY — TELEVISION FRESNEL
Ref. Qty. Description Item Number
50 1 Lampholder N00-AS313-360
51 1 Screw, pan head, 6-32 x 1/2"
52 1 Cable clamp
53 2 Rivet, pop
54 1 Nomex insulator
PK-93197-10-00-0A
