2
Installation
WARNING!
All electrical equipment work must be carried out by a qualified electrician
All electrical power must be isolated before work is carried out
• Disconnect Power
• Switches must be fittedto a flat surface ±1mm
• Use supplied mounting template/information below – drill a 25mm (1”) dia central hole through deck
• Locate switch & mark fixing points then drill holes suitable for chosen fixings – screw or bolt heads
must be countersunk to match hole form in switch to be flush.
• Use a sealing compound suitable to mate switch and deck surfaces to maintain IP67 and compound
must be suitable to survive in environment.
• Use an even force on all 3 fixings, do not over-tighten.
• Make electrical connections as per product manual
• Follow relevant standards and guidelines for electrical installations; use ISO 10133 as minimum
requirement.
• See Inspection & Maintenance instructions before use.
Notes:
• Switch is for use in DC voltage systems only
• If installed in vessel containing AC circuits follow ISO 10133 for correct wiring installation
• Switch is not intended for use in ignition protected areas
• It is the responsibility of installer to maintain IP67 sealing through deck upon installtion.
Operation
• Operation of switch must be in accordance with instructions and warnings from product manual
• Deck switches are designed to be used in conjunction with Lewmar equipment only.
• Deck switches should only be operated with fingers, bare feet or so soled shoes.
Switch may be finger operated through lid on open access version
Li lid to operate switch by foot, close lid aer use
Do not use hard soled shoes or sharp objects to operate switch
• Switches should be le with the lid closed to minimise environmental degradation and the potential for
accidental operation or impact damage.
• Powered deck equipment should always be isolated when not in use to prevent accidental start up.
• The instructions for the equipment being operated should always be read and followed.
• Power washers should not be used on or near any switch.
• It is acknowledged that deck switches will need to be washed down as part of a deck cleaning process.
However, direct flow from a non pressure hose should not be aimed at the switch.
• The deck switch itself should only be cleaned with a mild soap and washed off immediately with a light
application of fresh water.
• The following (non exhaustive) list of substances should not be applied, or used on or near any deck
switch. Products include but are not limited to:-
- Chemicals
- Deck cleaners
- Petroleum based fluids/cleaners
- Deck polish
- Deck brightener
- Varnish/lacquers/paints
- Oil
⚠
