3-7
Controlling the LXP-15
Owner's Manual Addendum
MIDI data from the input port which is
not connected
to the LXP-15 can be
merged with the data at the output port used for two-way communication.
This is useful when you are using an LXP-15 register that uses MIDI sources
for patching. Merging functions are selected on page 1 of the SYSTEMS
PARAMETERS menu. The different merging options are outlined in the
following table:
Merging Options for Two-way Communication
IN1 -> OUT1 <ON/OFF> Must be set to “OFF” if IN1/OUT1 are being used for
two-way communication with the LXP-15.
IN1 -> OUT2 <ON/OFF> If IN2/OUT2 are being used for two-way communi-
cation with the LXP-15, any combination of MIDI
controllers, Pitch Bend, Aftertouch, Note numbers
and Program Change messages received on IN1
can be merged with MIDI OUT2 by setting this to
“ON”.
IN 2 -> OUT2 <ON/OFF> Must be set to “OFF” if IN2/OUT2 are being used for
two-way communication with the LXP-15.
IN2 -> OUT1 <ON/OFF> If IN1/OUT1 are being used for two-way communi-
cation with the LXP-15, any combination of MIDI
controllers, Pitch Bend, Aftertouch, Note numbers
and Program Change messages received on IN2
can be merged with MIDI OUT1 by setting this to
“ON”.
