Lexicon MRC V4.0 - Page 30

3-17
Controlling the LXP-15
Owner's Manual Addendum
Full
Page 5 DECAY SIZE DIFFUS -
Decay Size Diffus -
.6-6.1s 8M-87M 0-100% -
Page 6 INLVL WPAN DPAN OUTLVL
InLevl Wet Pan Dry Pan OutLevl
0-100% 100%L-51%L, 100%R-51%R, 0-100%
Center, Center,
51%R-100%R 51%R-100%R
Chorus Delay
Page 1 MIX DELY1 DELY2 CHRAT
Mix Delay 1 Delay 2 ChorRat
0-100% 0-794ms 0-1.04s 1-16
Page 2 DELY3 - FDBK3 LFO
Delay 3 - Feedbk3 LFO Rat
0-1.04s - -99% to +99% .03Hz-4.84Hz
Page 3 PITCH N/A THIS ALGO
-- --
-- --
Page 4 - - TREBLE -
- - Treble -
- - 320Hz-11.6kHz, -
Full
Page 5 - - DIFFUS -
- - Diffus -
- - 0-100% -
Page 6 INLVL WPAN DPAN OUTLVL
InLevl Wet Pan Dry Pan OutLevl
0-100% 100%L-51%L, 100%R-51%R, 0-100%
Center, Center,
51%R-100%R 51%R-100%R
