CHARACTERISTICS
RECEIVER INPUTS/OUTPUTS
SPÉCIFICATIONS
NL
Reference: 83424577
Power supply: 230V~ 50Hz
Switching capacity: 230V~ 3A
Power consumption: < 1W
Max. power: 280W - 60 Nm Max
Radio protocol: Zigbee 3.0
Frequency band used: 2400.0 - 2483.5 MHz
Maximum radio power: +20dBm
Operating temperature: -20°C to 60°C
Protection class: IP 20
Dimensions: 40 mm (l) x 44 mm (L) x 16.9 mm (h)
Neutral input
Phase input
Wire switch input «up»
Wire switch input «down»
Motor output «up» direction
Motor output «down» direction
Each terminal must be connected by a cable of adequate section,
between 1.5 mm
2
and 2.5 mm
2
stripped by 8 mm.
