Assembly 29: Mailbox option 2
Asm-index P/N Units/mach Units/FRU Description Removal procedure
1 40X8250 1 1 Mailbox output bin LED assembly “Mailbox output bin LED assembly
removal” on page 720
2 40X8249 4 1 Mailbox belt “Mailbox belt removal” on page 718
3 40X8252 1 1 Mailbox spring with string “Mailbox spring with string removal”
on page 693
4 40X8721 2 2 Mailbox option latch “Mailbox option latch removal” on
page 697
5 40X8251 3 1 Mailbox solenoid “Mailbox solenoid removal” on
page 694
6 40X8243 1 1 Mailbox right cover “Mailbox right cover removal” on
page 691
4063
Parts catalog
866
