Lexmark T65 Series Service Manual

Parts catalog 7-9
7462
Go Back
Previous
Next
Assembly 4: Media path and ducts
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4384 1 1 EP cooling fan duct
2 40X1868 2 1 Print cartridge clamp assembly
3 40X4390 4 1 Machine pad
4 40X1869 1 1 Transfer deflector with static brush
5 40X1900 1 1 Media turn guide with actuator
6 40X4388 1 1 Inner deflector
7 40X4406 2 1 Print cartridge support roller
8 40X4395 1 1 Tray roller catch assembly
9 40X4394 1 1 Tray catch spring
10 40X4385 1 1 Envelope feeder interface cover (X658 only)
11 40X1876 1 1 MPF gear shield
12 40X4389 1 1 LVPS cooling duct
13 40X4486 1 1 Main cooling fan duct (X658DE)
13 40X4392 1 1 Main cooling duct (X651, X652, X654, and X656)
14 40X4318 1 1 Fuser access door assembly
