2-14 Service Manual
7510
Go Back
Previous
Next
231.01
Paper jam
Sensor (registration) late jam
(duplex media feed)
The media is late reaching the sensor (registration)
within the specified time after reaching the sensor
(duplex wait).
Go to “231.01 Sensor (registration) late jam
(duplex media feed)” on page 2-51.
241.00
Paper Jam
Sensor (tray 1 feed-out) late
jam.
The media is late reaching the sensor (tray 1 feed-
out) within the specified time after the tray 1 media
feed lift motor is turned on.
Go to “241.00 Sensor (tray 1 feed-out) late jam”
on page 2-53.
242.00
Paper jam
Sensor (tray 2 feed-out) late
jam.
The media is late reaching the sensor (tray 2 feed-
out) within the specified time after the tray 2 media
feed lift motor is turned on.
Go to “242.00 Sensor (tray 2 feed-out) late jam”
on page 2-55.
242.01
Paper jam
Sensor (tray 1 feed-out) late
jam (feeding from tray 2)
The media is late reaching the sensor (tray 1 feed-
out) within the specified time after reaching the
sensor (tray 2 feed-out).
Go to “242.01 Sensor (tray 1 feed-out) late jam
(feeding from tray 2)” on page 2-56.
243.00
Paper jam
Sensor (tray 3 feed-out) late
jam.
The media is late reaching the sensor (tray 3 feed-
out) within the specified time after the tray 3 media
feed lift motor is turned on.
TTM equipped machines go to “243.00 Sensor
(tray 3 feed-out) late jam” on page 2-57.
3TM equipped machines refer to the Options
Service Manual.
243.01
Paper jam
Sensor (tray 2 feed-out) late
jam (feeding from tray 3)
The media is late reaching the sensor (tray 2 feed-
out) within the specified time after reaching the
sensor (tray 3 feed-out).
TTM equipped machines go to “243.01 Sensor
(tray 2 feed-out) late jam (feeding from tray 3)”
on page 2-59.
3TM equipped machines refer to Options Service
Manual.
244.00
Paper jam
Sensor (tray 4 feed-out) late
jam.
The media is late reaching the sensor (tray 4 feed-
out) within the specified time after the tray 4 media
feed lift motor is turned on.
TTM equipped machines go to “244.00 Sensor
(tray 4 feed-out) late jam” on page 2-61.
3TM equipped machines refer to Options Service
Manual.
244.01
Paper jam
Sensor (tray 3 feed-out) late
jam (feeding from tray 4)
The media is late reaching the sensor (tray 3 feed-
out) within the specified time after reaching the
sensor (tray 4 feed-out).
TTM equipped machines go to “244.01 Sensor
(tray 3 feed-out) on jam (feeding from tray 4)” on
page 2-63.
3TM equipped machines refer to the Options
Service Manual.
Error code or
message
Error contents Description/Action
