Diagnostic information 2-39
7510
Go Back
Previous
Next
Service checks
200.00 Sensor (registration) late jam
Step Check Yes No
1 Check the media position.
Does the media touch the sensor (registration)?
Remove the
media.
Go to step 2.
2
Check the registration/transport roll assembly.
Is the above component free of excess wear and
contamination?
Go to step 3. Clean or replace
the registration /
transport roll
assembly.
Go to
“Registration /
transport roll
assembly
removal” on
page 4-46.
3
Check the sensor (registration) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch BASE SENSOR TEST.
3. Touch Media Path.
4. Touch Registration.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 5. Go to step 4.
4
Check the sensor (registration) for proper connection.
Is the above component properly connected?
Replace the
sensor
(registration).
Go to “Sensor
(registration)
removal” on
page 4-47.
Replace the
connection.
5
Check the transport roll/MPF drive motor assembly for
proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Printer Motor Test.
4. Touch MPF/transport drive motor.
Does the above component operate properly?
Go to step 7. Go to step 6.
6
Check the MPF / transport drive motor assembly for proper
connection.
Is the above component properly connected?
Replace the MPF/
transport drive
motor assembly.
Go to “MPF /
transport drive
motor assembly
removal” on
page 4-114.
Replace the
connection.
