244.01 Sensor (tray 3 feed-out) on jam (feeding from tray 4)
Step Check Yes No
1 Check the media condition.
Is the media in the tray crumpled or damaged?
Replace the
damaged media with
new.
Go to step 2.
2
Check the media position.
Does the media touch the sensor (tray 3 feed-out)?
Remove the media. Go to step 5.
3
Check the sensor (tray 3 feed-out) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 3.
5. Touch Feed-out.
Does the display on the operator panel, change every
time the sensing area of the above sensor is interrupted
or blocked?
Go to step 5.
Go to step 4.
4
Check the sensor (tray 3 feed-out) for proper
connection.
Is the above component properly connected?
Replace the sensor
(tray 3 feed-out).
Replace the
connection.
5
Check the sensor (tray 4 feed-out) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 4.
5. Touch Feed-out.
Does the display on the operator panel, change every
time the sensing area of the above sensor is interrupted
or blocked?
Go to step 7.
Go to step 6.
6
Check the sensor (tray 4 feed-out) for proper
connection.
Is the above component properly connected?
Replace the sensor
(tray 4 feed-out).
Replace the
connection.
7
Check the tray module drive motor for proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Printer motor tests.
4. Touch Tray module drive motor.
Does the above component operate properly?
Go to step 9. Skip to step 8.
