843.01 Scanner carriage over run error
4
Check the scanner drive motor assembly.
Caution: When performing motor tests, ensure
that all cover and door interlock switches are
overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch Scanner drv mtr.
5. Touch Forward or reverse.
Does the scanner drive motor assembly operate properly?
Go to step 6. Go to step 5.
5
Check the scanner drive motor assembly for connection.
Is the above component properly connected?
Replace the
scanner drive
motor assembly.
Go to “Scanner
drive motor
assembly
removal” on
page 4-128.
Replace the
connection.
6
Place media on the large platen and perform a scanner test.
Does the error remain?
Replace the
scanner
controller card
assembly.
Go to “Scanner
controller card
assembly
removal” on
page 4-130.
Problem solved.
Step Check Yes No
1 Check the connections of the scanner controller card
assembly.
Are the connectors of the scanner controller card assembly
connected properly?
Go to step 2. Connect each
connector of the
scanner
controller card
assembly
properly.
2
Perform a POR.
Does the error remain when the power is turned off/on?
Replace the
scanner
controller card
assembly.
Go to “Scanner
controller card
assembly
removal” on
page 4-130.
Problem solved.
Step Check Yes No
