Lexmark X945e MFP 7510 series User Manual

Diagnostic information 2-181
7510
Go Back
Previous
Next
925.00 Sensor (Y ATC) error
925.01 Sensor (M ATC) error
5
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the upper
printer engine card
assembly. Go to
“Upper printer
engine card
assembly
removal” on
page 4-88.
Problem solved.
Step Check Yes No
1 Reset the Y ATC failure lock out condition.
1. Enter diagnostic mode
2. Touch ATC sensor failure clear
3. Touch Y channel (925.00)
Perform a very large print test.
Does the error remain?
Go to step 2. Problem solved.
2
Check the sensor (Y ATC) for proper connection.
Is the above component properly connected?
Replace the Y
developer unit
assembly.
Go to “Developer
unit assembly
removal” on
page 4-63.
Replace the
connection.
3
Perform a very large print test.
Does the error continue?
Replace the upper
printer engine card
assembly.
Go to “Upper
printer engine
card assembly
removal” on
page 4-88.
Problem solved.
Step Check Yes No
1 Reset the M ATC failure lock out condition.
1. Enter diagnostic mode
2. Touch ATC sensor failure clear
3. Touch M channel (925.01)
Perform a very large print test.
Does the error remain?
Go to step 2. Problem solved.
Step Check Yes No
