2-204 Service Manual
7510
No media in the selected media tray
7
Perform a print test.
Does the error remain?
Replace the printer
engine card
assembly.
Go to “Upper
printer engine card
assembly removal”
on page 4-88.
Problem solved.
Step Check Yes No
1 Check the media.
Is media loaded in the selected tray?
Go to step 2. Load media
properly.
2
Check the sensor (media out) for operation.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 1.
5. Touch Media out.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 2.
5. Touch Media out.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 3.
5. Touch Media out.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 4.
5. Touch Media out.
Does the display on the operator panel, change every time
the sensing area of the above sensor is interrupted or
blocked?
Go to step 4. Go to step 3.
Step Check Yes No
