Lexmark X945e MFP 7510 series User Manual

Repair information 4-267
7510
Go Back
Previous
Next
Belt edge learn test
Skew fine setup
Step Check Yes No
1 Perform the Belt edge learn test.
1. Enter the Diagnostics Menu.
2. Touch ENGINE ADJUST.
3. Touch RegCon adjust
4. Touch Belt edge learn
Does the above test pass?
Perform “Skew
setup”.
See “Skew fine
setup” on
page 4-267.
Go to step 2.
2
Replace the transfer belt unit assembly.
See “Transfer belt unit assembly removal” on
page 4-16.
Does the error continue?
Perform “Skew
setup”.
See “Skew fine
setup” on
page 4-267.
Contact next level
of support.
Step Check Yes No
1 Perform the Skew fine setup.
1. Enter the Diagnostics Menu.
2. Touch ENGINE ADJUST.
3. Touch RegCon adjust
4. Touch Control setup cycles
5. Touch Skew fine setup
Does the above test pass?
Go to step 2. Go to step 3.
