Parts catalog 7-49
7510
Assembly 39: ADF feeder roll
Asm
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X2383 1 1 ADF main feed assembly (this comes assembled)
2 40X2346 1 1 Manual feed drive wheel
3 40X2345 1 1 Manual feed drive belt
4 40X2291 3 4 Plastic ring clip kit includes:
• Plastic ring clip 6 mm
• Plastic ring clip 8 mm
5 40X2337 4 1 Bearing 8 mm
6 40X2339 2 1 Bushing 8 mm
7 40X2336 1 1 ADF transport roll assembly
8 40X2333 1 1 ADF registration roll assembly
9 40X2334 1 1 ADF feed-out roll assembly
10 40X2335 1 1 ADF exit roll assembly
11 40X2349 1 1 Registration main drive pulley 21/54T
12 40X2342 1 1 Exit roll drive pulley 20T
13 40X2347 1 1 Exit roll drive belt
14 40X2350 1 1 Registration secondary drive belt
15 40X2341 1 1 Exit/feed-out roll drive pulley 25/28T
16 40X2340 1 1 Registration roll drive pulley 28T
17 40X2351 1 1 Retainer spring
18 40X2348 1 1 Tension spring
19 40X2343 1 1 Transport roll drive gear 20T
20 40X2338 2 1 Bushing 6 mm
21 40X2223 13 1 Sensor (document set)
22 40X2344 1 1 Manual feed drive pulley
