7-56 MFP Service Manual
7510
Assembly 44: Control panel and platen glass
Warning: In the event of replacement of any one of the following components:
•RIP card assembly
• Interconnect card assembly
Only replace one component at a time. Replace the required component, and perform a POR before replacing a second
component listed above. If this procedure is not followed, the printer will be rendered inoperable. Never replace two or more
of the components listed above without a POR after installing each one, or the printer will be rendered inoperable.
Warning: Never install and remove components listed above as a method of troubleshooting components. Once a
component has been installed in a machine, it cannot be used in another machine. It must be returned to the manufacturer.
Asm
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X2215 1 1 Small platen glass rear retainer
2 40X2214 1 1 Small platen glass
3 40X2213 1 1 Small platen glass front retainer
4 40X2208 1 1 Large platen glass
5 40X3858 1 1 Large platen glass retainer
6 40X3863 1 1 Operator panel bezel X940e model
6 40X3870 1 1 Operator panel bezel X945e model
7 40X4096 1 1 Operator panel assembly (universal)
8 40X2363 1 1 Operator panel controller card assembly
9 40X2364 1 1 Operator panel inverter card assembly
10 40X2362 1 1 Operator panel user touch screen
11 40X2365 1 1 USB interface card assembly
12 40X3859 1 1 Operator panel cable assembly
NS 40X8459 1 1 USB connector assembly
