Standard trays and special trays
The Lexmark T640, T642, and T644 paper feeding mechanism uses advanced technology that enhances feeding
reliability. The standard Lexmark T640, T642, and T644 tray holds 250 or 500 sheets of bond paper and reliably feeds
all media tested according to the guidelines specified under “Dimensions” on page 9.
For those difficulttoprint sizes, such as 3 x 5inch index cards, Lexmark offers a variety of special media trays and
drawers.
Note: Optional 250sheet Universally Adjustable Trays can be used to print forms with a minimum length of 5 inches
when installed either in the integral tray location or in a 250sheet drawer under a 250sheet integral tray. Forms
less than 7 inches long are not supported from a 400sheet universally adjustable tray.
Standard and special trays
Source Part number
250Sheet Mild Special Media Tray 20G1237
250Sheet Aggressive Special Media Tray 20G1230
250Sheet Mild Special Media Drawer 20G1236
250Sheet Aggressive Special Media Drawer 20G1229
250Sheet Universally Adjustable Tray 20G1224
250Sheet Universally Adjustable Drawer 20G1223
500Sheet Mild Special Media Tray 20G1240
500Sheet Mild Special Media Tray + Drawer 20G1239
500Sheet Aggressive Special Media Tray 20G1227
500Sheet Aggressive Special Media Tray + Drawer 20G1226
400Sheet Universally Adjustable Tray 20G1217
400Sheet Universally Adjustable Tray + Drawer 20G1218
Card stock and label guidelines
Labels are one of the most difficult print materials for laser printers. A special fuser cleaner should be used for label
applications to optimize feed reliability. See your printer documentation for information on ordering additional label
fuser cleaners.
Printing labels on the T640, T642, and T644 requires a special label fuser cleaner that prevents duplexing.
It is recommended that when you run vinyl labels, you install a special oil fuser cleaner, P/N 40X2665. When you order
a new cartridge, be sure to order the cartridge that will include the correct fuser cleaner.
It is possible to duplex certain labels that have been specifically designed for this application. To duplex labels, consult
the Lexmark "Converter Lists" to see which converters have successfully developed this type of label, and you must
install a special fuser wiper. The wax wiper that is used with the T640, T642, and T644 is P/N 40X2666. (Cartridges
designed for duplex label printing contain two wax wipers. Change the wax wiper at the halfway point of your normal
cartridge usage to provide additional cleaning and optimize performance.)
Printer specifications 103

Table of Contents

Other manuals for Lexmark XM3150

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Lexmark XM3150 and is the answer not in the manual?

Lexmark XM3150 Specifications

General IconGeneral
Duplex printingYes
Print technologyLaser
Maximum resolution1200 x 1200 DPI
Time to first page (black, normal)6.5 s
Print speed (black, normal quality, A4/US Letter)47 ppm
All-in-one functionsCopy, Fax, Print, Scan
Color all-in-one functionsScan
Digital senderNo
Maximum duty cycle150000 pages per month
Recommended duty cycle2000 - 15000 pages per month
Copier resize25 - 400 %
Maximum copy resolution- DPI
Copy speed (black, normal quality, A4)47 cpm
Scan speed (black)48 ppm
Scan speed (color)32 ppm
Duplex scan speed (black)21 ppm
Duplex scan speed (color)14 ppm
Optical scanning resolution600 x 1200 DPI
FaxingMono faxing
Modem speed33.6 Kbit/s
Total input capacity650 sheets
Total output capacity250 sheets
Maximum input capacity2300 sheets
Multi-Purpose tray input capacity100 sheets
Envelopes sizes7 3/4, 9, 10, DL
Maximum print size216 x 356 mm
Paper tray media typesCard stock, Envelopes, Labels, Plain paper, Transparencies
Non-ISO print media sizesExecutive (184 x 267mm), Folio (media size), Legal (media size), Letter (media size), Oficio (media size)
ISO A-series sizes (A0...A9)A4, A5, A6
JIS B-series sizes (B0...B9)B5
Maximum ISO A-series paper sizeA4
DisplayLCD
Control typeTouch
Product colorGrey, White
Display diagonal7 \
Market positioningBusiness
Direct printing-
Standard interfacesEthernet, USB 2.0
Optional connectivityParallel, Serial (RS-422), Wireless LAN
Internal memory1024 MB
Maximum internal memory3072 MB
Sound pressure level (copying)56 dB
Sound pressure level (printing)55 dB
Power consumption (average operating)- W
Operating altitude0 - 2896 m
Operating temperature (T-T)16 - 32 °C
Operating relative humidity (H-H)8 - 80 %
Sustainability certificatesENERGY STAR
Weight and Dimensions IconWeight and Dimensions
Depth479 mm
Width499 mm
Height561 mm
Weight23600 g
