502
4-3. Do-it-yourself maintenance
11
PD 50 A
Daytime running light system, A/F,
H-LP RH HI, H-LP LH LO, H-LP RH
LO, H-LP LH HI, HORN, S-HORN,
multiplex communication system,
multiport fuel injection system/
sequential multiport fuel injection sys-
tem
12
ABS NO. 1 50 A Anti-lock brake system
13
EPS 60 A Electric power steering system
14
ALT 140 A
FUEL OPN, DR LOCK, OBD, RR
FOG, S/ROOF, 4WD, INVERTER,
ECU IG1 NO. 1, ECU IG1 NO. 2,
PANEL, GAUGE NO. 1
15
AMP1 30 A Audio system
16
EFI MAIN 30 A
Multiport fuel injection system/
sequential multiport fuel injection sys-
tem, EFI NO. 1, EFI NO. 2
17
AMP2 30 A Audio system
18
IG2 30 A
Starter system, IGN, GAUGE NO. 2,
ECU IG2
19
IP JB 25 A Power door lock system
20
STR LOCK 20 A Starter system
21
RAD NO. 3 15 A
Meters and gauges lights, instrument
panel lights, navigation system, audio
system, rear seat entertainment sys-
tem
22
HAZ 15 A Emergency flashers
Fuse Ampere Circuit
