8-1. Specifications
LC500_LC500h_OM_OM11405U_(U)
8
Vehicle specifications
*1
: Minimum pedal clearance when depressed with a force of 112.4 lbf (500 N, 51.0 kgf)
while the engine is running <hybrid system is operating>.
When performing the brake pedal inspection, also be sure to check that the brake sys-
tem warning light is not illuminated when the engine is running <hybrid system is operat-
ing>. (If the brake system warning light is illuminated, refer to P.334.)
*2
: Make sure to confirm that the brake warning light (yellow) does not illuminate. (If the
brake warning light illuminates, refer to P.338.)
Type A
Parking brake indicator
*2
When pushing the parking brake switch for
1 to 4 seconds: comes on
When pulling the parking brake switch for 1
to 4 seconds: turns off
Fluid type SAE J1703 or FMVSS No.116 DOT 3
Steering
Free play Less than 1.2 in. (30 mm)
Tires and wheels
Tire size
Front tires: 245/45RF20 99Y
Rear tires: 275/40RF20 102Y
Tire inflation pressure
(Recommended cold tire inflation pressure)
Driving under normal conditions
Front: 33 psi (230 kPa, 2.3 kgf/cm
2
or bar)
Rear: 33 psi (230 kPa, 2.3 kgf/cm
2
or bar)
Driving at high speeds (above 137 mph
[220 km/h]) (in countries where such
speeds are permitted by law)
Add 10 psi (70 kPa, 0.7 kgf/cm
2
or bar) to
the front tires and rear tires. Never exceed
the maximum cold tire inflation pressure
indicated on the tire sidewall.
Wheel size
Front wheels: 20 8 1/2J
Rear wheels: 20 9 1/2J
Wheel nut torque 103.3 ft•lbf (140 N•m, 14.3 kgf•m)
To Next Page
