20
8. Remove the 2 clips and motor cable cover.
9. Remove the 2 clips and inverter cover assembly.
10. Remove the 2 bolts and connector cover assembly 10 minutes or more after removal
of the service plug grip.
Caution:
Wear insulated gloves.
Notice:
Do not touch the high voltage connectors or terminals for 10 minutes after the service
plug grip is removed.
Connecter cover
For LHD
For RHD
For LHD
For RHD
For LHD
For RHD
