a. Install the vane pump rotor.
HINT:
The vane pump rotor can be installed in both directions.
b. Coat the 10 vane pump plates with power steering fluid.
c. Install the vane pump plates with the round end facing outward.
NOTICE:
Make sure that the vane pump plates are installed facing in the correct
direction.
6. INSTALL VANE PUMP SHAFT SNAP RING
a. Using a screwdriver and snap ring expander, install a new shaft snap ring onto
the vane pump shaft.
NOTICE:
Do not expand the shaft snap ring any further than needed.
Make sure that the shaft snap ring is completely fit into the
groove.
Do not damage the vane pump rotor and shaft.
7. INSTALL VANE PUMP REAR HOUSING
a. Coat a new O-ring with power steering fluid and install it onto the rear housing.
