NOTICE:
Do not mistake the direction of the control valve.
c. Coat a new O-ring with power steering fluid and install it onto the pressure port
union.
d. Install the pressure port union to the front housing.
Torque:
69 N*m{ 704 kgf*cm , 51 ft.*lbf }
10. FIX VANE PUMP ASSEMBLY
a. Using SST, fix the vane pump in a vise.
SST
09630-00014 (09631-00132)
11. INSTALL POWER STEERING SUCTION PORT UNION
a. Coat a new O-ring with power steering fluid and install it to the suction port union.
b. Install the suction port union to the vane pump with the bolt.
Torque:
12 N*m{ 122 kgf*cm , 9 ft.*lbf }
