7. REMOVE LOWER STEERING COLUMN COVER
a. Remove the 3 screws.
b. Detach the 2 claws to remove the lower steering column cover.
NOTICE:
Do not damage the tilt and telescopic switch.
8. REMOVE UPPER STEERING COLUMN COVER
a. Detach the 4 clips.
b. Detach the claw to remove the upper steering column cover.
9. REMOVE TILT AND TELESCOPIC SWITCH
a. Disconnect the switch connector.
b. Using a screwdriver, detach the claw and pull out the switch.
HINT:
Tape the screwdriver tip before use.
NOTICE:
Pushing on the claw too hard will break the claw.
10. REMOVE COMBINATION SWITCH ASSEMBLY WITH SPIRAL CABLE SUB-ASSEMBLY
a. Disconnect the 5 connectors from the turn signal switch with spiral cable.
