i. With the engine idling and the valve fully open, turn the steering wheel left or
right to the full lock position. Observe the reading on SST.
Standard fluid pressure:
10000 to 10700 kPa (102 to 109 kgf/cm
2
, 1450 to 1552 psi)
NOTICE:
Do not keep the steering wheel in the full lock position for more
than 10 seconds.
Do not allow the fluid temperature to become too high.
If the pressure is less than the standard, check for fluid leaks and replace parts
as necessary.
j. Disconnect SST.
SST
09640-10010 (09641-01010, 09641-01030, 09641-01060)
k. Connect the pressure feed tube (Click here).
l. Bleed the power steering system.
