LEYBOLD MAG Series User Manual

GA05141_0702 - 09/2004
22
Description
Pump configuration
Inlet Forevacuum Purge Purge valve Cooling Temperature
Pump flange flange gas mounted to Rotor water sensor for TMS** Part No.
DN DN connection pump coated connection cooling water
MAG W 830 C 160 ISO-F 40 KF DN 10/16 no* yes Swagelock 1/4“ no no 400100V0005
tube connector
MAG W 1300 C 200 ISO-F 40 KF DN 10/16 no* yes John-Guest fitting no no 400110V0011
6 mm Rohr
MAG W 1300 C 200 ISO-F 25 KF VCR no* yes Swagelock 1/4“ tube no no 400110V0017
(bended)
MAG W 1300 C 250 ISO-F 40 KF DN 10/16 no* yes John Guest fitting no no 400110V0021
6 mm tube
MAG W 1300 C 250 ISO-F 40 KF DN 10/16 no* yes Swagelock 1/4“ no no 400110V0023
tube connector
MAG W 1300 C 250 ISO-K 40 KF DN 10/16 no* yes Swagelock 1/4“ no no 400110V0121
tube connector
MAG 1500 CT 200 ISO-F 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes yes 400020V0002 MAG 1500 CT 250 ISO-F 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes yes 400021V0002 MAG W 1500 CT 200 ISO-F 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes yes 400026V0002 MAG W 1500 CT 250 ISO-F 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes yes 400027V0002 MAG W 1500 CT 200 CF 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes yes 400030V0002 MAG W 2200 C 200 ISO-F 40 KF VCR Nut 1/4“ no yes Stainless steel yes no 400081V0011
hose nipples 1/2“
MAG W 2200 C 250 ISO-F 40 KF VCR Nut 1/4“ no yes Stainless steel yes no 400081V0021
hose nipples 1/2“
MAG W 2200 C 250 ISO-F 40 KF Thread 1/4“ yes yes Thread 1/8“ no no 400081V0020 MAG W 2800 C 250 ISO-F 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes no 400000V0001 MAG W 2800 CT 250 ISO-F 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes yes 400000V0002 MAG W 3200 CT 320 ISO-F 40 KF VCR Nut 1/4“ yes yes Swagelock 1/4“ tube yes yes 400003V0002 MAG W 830 160 CF 40 KF DN 10/16 no* no Swagelock 1/4“ tube no no 400100V0041 MAG W 1300 200 CF 40 KF DN 10/16 no* no Swagelock 1/4“ tube no no 400110V0051 MAG W 2200 250 CF 40 KF DN 10/16 no* no Swagelock 1/4“ tube no no 400081V0061 MAG W 2800 250 CF 40 KF DN 10/16 no* no Swagelock 1/4“ tube no no 400006V0071 * Purge vent valve Part No. 121 36 or purge vent Tee can be mounted ** Heater band and temperature sensor for pump control

LEYBOLD MAG Series Specifications

General

Applications	Laboratory, medical, and industrial applications
Drive	Magnetic drive
Sealing	Hermetically sealed
Flow Rate	Varies depending on the model, ranging from a few liters per minute (LPM) to several tens of LPM. Consult specific model datasheets for precise values.
Max Pressure	Varies by model (typically up to 10 bar)
Power Supply	Typically available in various AC voltages (e.g., 115V, 230V) and frequencies (50/60 Hz)
Power Consumption	Varies depending on the model, ranging from a few watts to several hundred watts. Consult specific model datasheets for precise values.
Operating Temperature	Typically 0°C to +60°C
Weight	Varies depending on the model, ranging from a few kilograms to several kilograms. Consult specific model datasheets for precise values.
Dimensions	Varies depending on the model. Consult specific model datasheets for precise dimensions.
Materials	Stainless steel
