LFE 2000 Series - Page 112

958-31
REV.
B
SECTION I1
-
CHECKLIST
Before shiprng any
controller
that has
been modifred
or recalibrated,
make sure
that:
l) APPLICATION
CONFIGUMTION
atrees
with customer specifications.
2) CASE and PART NUMBER
labels rnclude all
modlfications
made
includj-ne
SPAN
(and
CAL values for voltage or
current Inputs).
3)
EPROM and uP are firmly
in their sockets.
4)
I/0 and CPU boards are
firnrly 1n their bezel
asserrbly
connectors.
5)
Spacer rod(s) between
I/0 and CPU boards
is firrnly in
place.
6)
Al1 other
plug-ln
connections
are
trght.
7)
Electronrc
assembly
is
properly
mounted in
the case, right
slde up and snug.
8)
Rear terminal screws
(see
note) are in
place.
Cold
Junction resistor
in
place
on thermocouple
input units
or removed from RTD and DC input
units.
9)
01der units
with the cold
junctron
thermocouple cornpensator mounted
on the rear
case
terninals, have the
same cold
junction
resistor lnstalled
on the rear
that
was used for input
callbration.
10)
A11 control
functions and outputs
have been
properly
tested.
(See
sectron 7).
-:-i!
NOTE
/r*
MOST REAR
TERMINAL SCREWS ARE
IN A SEPARATE KIT AND NOT INSTALLED
AT
THE FACTORY.
-105-
LFE Instruments
Divlsron
